Self-priming JET pump JET-A

Application Limits


Suction head up to 9m

Max.working pressure 5 bar

Liquid temperature up to +40℃

Ambient temperature up to +40℃

pH:6.5 to 8.5


Pump range


Max. Flow: 10.5m3/h

Max.Head: 50m


Motor


2-pole induction motor, 50Hz(n=2800rpm)

Single-phase 220V士10%

Heavy Duty Continuous Work

Copper winding

Shaft: AISI304 welding shaft

Insulation: Class B / Class F

Protection: IPX4

Built-in thermal protector for single phase




Optional available on request


NSK bearing

Motor insulation class is F

Other voltage or frequency is 60Hz

Nylon impeller
